6TR40 Series transmission

Category：

Six-speed transmission

Product Description

ZQC6TR40变速器主要技术参数表

No.	Parameter	ZQC6TR40
1	Basic Structure	Rear-drive Drive Type: three-axis, all-synchromesh gear
2	Main Ratio	——
3	Speed/Ratio	Ⅰ	Ⅱ	Ⅲ	Ⅳ	Ⅴ	Ⅵ	R
3	Speed/Ratio	5.441	2.839	1.721	1.223	1.00	0.794	4.935
4	Center Distance	82 mm
5	Center Distance	420 N·m
6	Center Distance	Rear single-lever control
7	Lubricant Oil	2.4 L/GL-4
8	Weight(kg)	55 kg
9	Engine Type	RA425/大VAN
10	Overall Dimension（L×W×H）	630×440×425
10	Technical features	1, manual mechanical longitudinal straight rear-wheel drive transmission triaxial 2, all the die-casting aluminum housing, and product weight 3, the output shaft and the intermediate shaft are three-bearing support, improve system rigidity, reduce distortion 4, all gears fully synchronous design, twelve stalls three cone synchronizers, three or four stalls double cone synchronizers five or six and reverse single cone synchronizer. It has good synchronization performance 5, using the swing shift fork, shifting force to make lighter 6, all with fine high gear tooth design, with grinding teeth and tooth surface hardening process, reduce transmission noise, improve gear carrying capacity.
